ASI32012 LAFAYETTE Industrial Source 320 W 12 Amp 12 volt output

ASI 32012

ASI32012 LAFAYETTE Industrial Switched Power Supply 320 W, voltage 12 volts. amps 25 A.

Input voltage: 220 volts
Output amps: 25 A

Voltage output: 12 volts

Features

Caracteristicas

EMI complies with EN55022 (CISPR22) Class B
• Low Power consumption
  Approvals: UL / CUL / TUV / CB / CE
  Protections: Over load, over voltage, short circuit
  100% full high temperature load
  DC output: 12V 0 ~ 25A
  Input voltage range: 88 ~ 132VAC 176 ~ 264VAC selectable by switch
  Frequency input: 47 ~ 63Hz
  Current break: cold start, 15A / 115VAC, 30A / 230VAC
  Output range adjustment : 10% nominal output voltage
  Regulating line: <0.5%
  Output over load protections: 105% ~ 135% mode, auto recovery
  Output over voltage protections: 115% voltage ~ 145% output nominal
  Short output circuit protections: mode, self-recovery
  Rise, Retention time: 50 ms, 20 ms at full load (typical)
  Isolation:
  I / PO / P 3KVCA,
  E / P FG 1.5KVCA ,
  O / P FG 0.5KVCA
  Operating Temperature range:
  0 ° C to 40 ° C to 100%, 10 ° C to 80%,
  60 ° C @ 60%
  Safety standards: UL60950 1, TUV EN60950 1
  EMC standards: EN55022 class B, EN61000 3 2, 3
  EN61000 4 2, 3,4,5,6,8,11, ENV50204
  Cooling method: forced air cooling by the built-in DC fan
  cooling fan ON OFF control / auto
  Weight: 1.08Kg
  Peso: 1.08Kg
