K-PO TX-502N ROE SWR and power meter 1.6 at 525 Mhz. PL and N

K-PO TX-502N is a high precision cross-meter for Forward power, Reflected power and SWR, operating over a very wide frequency range between 1.6 and 525 MHz. It incorporates UHF female connectors for 1.6–200 MHz and N h more Manufacturer: kpo Reference KPOTX502N

Make the first review

kpo
K-PO TX-502N SWR and Power Meter, 1.6 to 525 MHz. Power range: 2, 20, and 200 watts. Crossed needles. PL female connectors for the 1.6 to 200 MHz range and N female connectors for the 125 to 525 MHz range. K-PO TX-502N SWR and Power Meter, 1.6 to 525 MHz. Power range: 2, 20, and 200 watts. Crossed needles. PL female connectors for the 1.6 to 200 MHz range and N female connectors for the 125 to 525 MHz range.
K-PO TX-502N SWR and Power Meter, 1.6 to 525 MHz. Power range: 2, 20, and 200 watts. Crossed needles. PL female connectors for the 1.6 to 200 MHz range and N female connectors for the 125 to 525 MHz range.
available
170,07€ incl. VAT
140,55€ w/o VAT
Delivery price from 30,25€
We're working in our new page, i'ts possible that you discover some mistakes. In that case, you can notify us clicking HERE.

K-PO TX-502N SWR and Power Meter

The K-PO TX-502N is a high-precision Forward, Reflected and SWR cross-meter, operating over a very wide frequency range between 1.6 and 525 MHz . It incorporates UHF female connectors for 1.6–200 MHz and N female connectors for 125–525 MHz, ensuring compatibility across the entire range. The large backlit display allows simultaneous viewing of Forward, Reflected and SWR with clarity.

K-PO TX-502N Medidor ROE SWR y potencia 1,6 a 525 Mhz. Rango Potencia 2, 20 y 200 watios. Agujas cruzadas. Conectores PL hembra para el rango de 1,6 a 200 Mhz y N hembra para el rango de 125 a 525 Mhz

Some of the features that the K-PO TX-502N offers us are:

  • Backlit display for simultaneous reading of Forward Power, Reflected Power and SWR
  • AVG/PEP switch to alternate between average and peak power (PEP)
  • Wide frequency range: 1.6–525 MHz
  • Supports up to 200 W peak power (short periods)
  • High accuracy with ±10% of full scale or better
  • Standard impedance of 50 O
  • Very low insertion loss: < 0.1 dB
  • Minimum power to measure SWR: 1 W
What's included with the K-PO TX-502N?
  • 1 K-PO Crossover Meter TX-502N
  • 1 DC power cable (9–14 V, max. 200 mA)
  • 1 Installation Manual in English

Technical characteristics

  • Frequency: 1.6–525 MHz
  • RF connectors: UHF female for 1.6–200 MHz and N female for 125–525 MHz
  • Power ranges: 2 W / 20 W / 200 W
  • Accuracy: ±10% of full scale or better
  • Impedance: 50 O
  • Insertion loss: <0.1 dB
  • Minimum allowable power for SWR measurement: 1 W
  • Power supply: 9–14 V DC, up to 200 mA
  • Weight: approx. 1,070 kg
  • Dimensions: 184 × 118 × 131 mm
