K-PO TX-102 SWR Meter 1.6 to 200 MHz. PL female

K-PO TX-102 is a high precision cross-needle meter for measuring Forward Power, Reflected Power and SWR simultaneously, over a wide frequency range from 1.6 to 200 MHz. Its display shows the power level of the SWR. more Manufacturer: kpo Reference KPOTX102

Make the first review

K-PO TX-102 SWR Meter, 1.6 to 200 MHz. Power range: 2, 20, and 200 watts. Crossed needles. Female PL connectors.

available

143,60€ incl. VAT

118,68€ w/o VAT

Delivery price from 30,25€

We're working in our new page, i'ts possible that you discover some mistakes. In that case, you can notify us clicking HERE.

Description

K-PO TX-102 SWR and Power Meter

The K-PO TX-102 is a high precision cross-needle meter for measuring Forward Power, Reflected Power and SWR simultaneously over a wide frequency range of 1.6 to 200 MHz . Its backlit display allows clear reading of Forward, Reflected and SWR values at a glance. It has an AVG/PEP switch, useful for SSB or AM transmissions. It handles up to 200 W peak (short term) power . Manufactured by Nissei, Taiwan.
K-PO TX-102 Medidor R.O.E. SWR 1,6 a 200 Mhz. Rango de Potencia 2, 20 y 200 watios. Agujas cruzadas. Conectores PL hembra

Some of the features that the K-PO TX-102 offers us are:

Simultaneous measurement of Forward Power, Reflected Power and SWR
AVG/PEP switch to choose average or peak power
Backlit display for excellent visibility
Wide frequency range: 1.6200 MHz
Supports up to 200 W peak power
High accuracy: ±10% of full scale or better
Impedance: 50 O
Insertion loss: < 0.1 dB
Minimum power to measure SWR: 1 W

What's included with the K-PO TX-102?

1 K-PO TX-102 Meter
1 DC power cable (914 V, < 200 mA)
1 Installation Manual in English

Technical characteristics

Frequency: 1.6200 MHz
Impedance: 50 O
Powers: 2 W, 20 W, 200 W
Accuracy: ±10% FS
Minimum power SWR: 1 W
Insertion loss: < 0.1 dB
Power supply: 914 V DC, up to 200 mA
RF Connectors: UHF (PL) female input/output
Dimensions: 184 × 118 × 131 mm
Weight: approx. 910 g
