K-PO TX-101A SWR Meter 1.6 to 60 MHz. Female PL Cross Needles

The K-PO TX-101A is a backlit analog cross-needle power (Forward/Reflected) and VSWR meter, designed for operation between 1.6 and 60 MHz. Its large backlit display and AVG/PEP switch make it especially useful for SSB or AM transmissions. It provides more Manufacturer: kpo Reference KPOTX101A

Make the first review

K-PO TX-101A SWR Meter 1.6 to 60 MHz. Female PL Cross Needles

available

170,07€ incl. VAT

140,55€ w/o VAT

Delivery price from 30,25€

We're working in our new page, i'ts possible that you discover some mistakes. In that case, you can notify us clicking HERE.

Description

K-PO TX-101A SWR and Power Meter

The K-PO TX-101A is a backlit analog cross-needle power (Forward/Reflected) and VSWR meter, designed to operate between 1.6 and 60 MHz . Thanks to its large backlit display and AVG/PEP switch, it is especially useful for SSB or AM transmissions. It allows very accurate power readings, including peak (PEP), and supports up to 2 kW peak in short period . Manufactured by Nissei (Taiwan).

Some of the features that the K-PO TX-101A offers us are:

Simultaneous measurement of Forward, Reflected and SWR power
AVG/PEP switch for average and peak power
Backlight for clear reading in low light conditions
Supports up to 2000 W (2 kW) peak power
Wide operating frequency: 1.660 MHz
High accuracy: ±10% of full scale
Minimum insertion: = 0.1 dB

What's included with the K-PO TX-101A?

1 K-PO TX-101A Meter
1 DC power cable (914 V, 200 mA max.)
1 Installation Manual in English

Technical characteristics

Frequency range: 1.660 MHz
Impedance: 50 O
Power ranges: 20 W, 200 W, 2000 W
Accuracy: ±10%
Minimum power for SWR: 1 W
Insertion loss: < 0.1 dB
Supply voltage: 914 V DC, = 200 mA
RF Connectors: UHF (PL) female for input and output
Weight: 900 g
Dimensions: 184 × 118 × 131 mm
