ICOM IC-R6 Portable Scanner 100 - 1309,995 Mhz Continuous band.

ICOM IC-R6

Although the Icom IC-R6 retains the basic characteristics of the ICOM IC-R5, it presents a new and improved design with new features.

The new Icom IC-R6 scanner has improved the tracking system (100ch / sec) also incorporating 1300 memory channels. The Icom IC-R6 has a reception capacity of approximately 15 continuous hours.

FEATURED FEATURES

100Khz / 1309.995MHz margin *

The receivers of the Icom IC-R6, in addition to operating in a wide band frequency range, and the design of its extremely high sensitivity radio stage, have characteristics in the receiver that make it insensitive to interference.
Amateur stations, AM, FM, short wave, radio broadcasting stations, TV audio * and a wide variety of broadcasts can be picked up on the Icom IC-R6 .

* The frequency range depends on the versions. Analog TV audio only. It cannot decode DTT.

High speed scan 100 channels per second

The Icom IC-R6 has a high speed scan * capable of scanning 100 channels per second.

* VFO scan mode.

Autonomy of 15 hours in continuous reception *

The energy efficiency in the design of the Icom IC-R6 , provides many hours of enjoyment with a simple charge. With the supplied Ni-Mh rechargeable batteries (2 x 1400mAh), the Icom IC-R6 has a range of up to 15 hours of continuous reception.

* At 50mW AF output using external speaker.

1300 memory channels with 22 banks

With 1300 alphanumeric memory channels, 50 scan ranges and 200 auto-recording memories, the Icom IC-R6 has a flexible scan system. By using the Linked Bank Scan feature you can select and connect to any of the 22 memory banks.

VSC (Voice Squelch Control)

The VSC opens the squelch only when a modulated signal is detected and ignores unmodulated beat noises. It is a characteristic for those listeners in search of conversations, music or news avoiding the data frames or radio beacons.

Multiple power options

The Icom IC-R6 can be powered by Ni-MH batteries, or alkaline batteries. Use the Icom IC-R6 with the BC-196S AC adapter or optionally with the CP-18 cigarette lighter cable.
When the BC-194 desktop charger is used with the AC adapter or cigarette lighter cable, you can easily charge Ni-MH batteries, while eliminating the need for
plugging the DC cable into the receiver's power connector.

Other features

- Audio low-pass filter as standard
- High frequency stability ± 1.0ppm (at 25ºC)
- Antenna on the headphone cable for AM aviation as well as FM broadcasting
- Ferrite bar antenna for AM broadcasting
- Powerful audio with 150mW internal speaker
- CTCSS DTCS tone squelch and inverted tone.
- Dual priority listening function with beep alert function.
- CI-V remote control with optional CT-17 level converter
- PC programming with optional CS-R6 software
- Receiver-to-Receiver cloning with optional cable OPC-474
- Auto power OFF function (from 0.5 to 2 hours at the end of the last transmission)
- Compact and moisture resistant construction
- Operation monitoring in duplex mode.
- Automatic display backlight
- Dial acceleration function
- Serial RF attenuator
- Automatic recording memories, store the frequency, mode and tone in a specific memory.
- Function of reversible up / down buttons and dial, for adjusting volume, frequency, memory, scan direction and configuration settings.

GENERAL

Frequency range 0.100 / 1309.995MHz (cell phone blocked in the USA version)

AM, FM, WFM modes

Number of memories
1,300 standard, 50 trace margins, and 200 auto-record

Temperature range -10 ° C to 60 ° C

Frequency stability ± 1.0ppm (at 25 ° C)

Frequency resolution 5, 6.25, 8.33 *, 9 *, 10, 12.5, 15, 20, 25, 30, 50, 100, 125, 200kHz
(* selectable depending on the bands.)

2 × R6 type AA alkaline or NI-MH power supply
Outside power supply
4.5Vdc nominal (4.5 to 6.3Vdc with BC-196SA / SD, CP-18A / E)
Nominal Audio Consumption
130mA typ (external speaker (at 3.0Vdc) Backlight off)
Standby 65mA typ
Economizer 30mA typ (load ratio 1: 4)

Antenna impedance 50 ohms (SMA)

Dimensions (W × H × D) 58 × 86 × 29.8 mm; (projections not included)

Weight (approx. 200g

Ext speaker connector
3-way 3.5mm / 8 ohm jack

All declared specifications are subject to change without obligation to notify.
