4.501,91€ VAT included
Reference AS5700 | AOR
AS5700 Professional Remote Antenna Switch
It is a professional remote antenna switch designed for radio frequency applications where automatic or manual switching between multiple antennas is required. This device is constructed with weather-resistant materials, ideal for outdoor installatio
Make the first reviewAdditional Services
Are you one of those who prefer not to wrap gifts? We do it for you!
With the Paper Gift Service, you will receive your product wrapped and ready to deliver to your recipient!
What if the recipient is you? Why not?
We all like to open a gift from time to time, so do not cut and hit the whim! We assure you that we will surround you with all the affection of the world.
This service is available for the following countries: España - Peninsula y Baleares, Canarias, Alemania, Bélgica, Eslovaquia, Eslovenia, Estonia, Francia, Grecia, Holanda, Irlanda, Italia, Letonia, Luxemburgo, Noruega, Polonia, Portugal, Reino Unido, República Checa, Suecia, Andorra, Austria, Bulgaria, Chipre, Dinamarca, Finlandia, Gibraltar, Hungría, Malta, Mónaco, Rumania, Suiza, Ceuta y Melilla, Gibraltar, Francia Corcega, Portugal - Azores y Madeira.
If in the purchase process you select a country, that are not specified in the list, we will delete automatically the service. Therefore you will not be charged anything. We are working to improve our services. So we will try, of course, to have this service in all countries.
available. Envio a partir de 2 días. Delivery price from 6,50€
Description AOR AS5700
The AS5700 is a professional remote antenna switch designed for radio frequency applications where automatic or manual switching between multiple antennas is required. This device is constructed with weather-resistant materials, ideal for outdoor installation, and delivers high-quality performance with minimal signal loss.
This selector supports up to six different antennas, switchable from a single remote control unit via an RS-232 interface or automated systems. Its electrical and mechanical features make it a reliable tool for both amateur radio operators and commercial or military systems.
Some of the features that the AS5700 offers us are:
- Remote control via RS-232 or custom controller
- High switching power: up to 3 kW PEP in SSB
- Isolation between ports greater than 60 dB
- SO-239 (UHF female) connectors on all ports
- Protection against electrical discharges and transients
- Designed for outdoor use (weather resistant)
What's included with the AS5700?
- 1 AS5700 Antenna Selector
- 1 Technical installation manual
Characteristics
- Operating frequency: 1.8 54 MHz
- Nominal impedance: 50 ohm
- Maximum power: 2 kW CW/FM/RTTY, 3 kW PEP on SSB
- Isolation between ports: > 60 dB
- Insertion loss: < 0.1 dB
- Control: RS-232 (DB-9) or customized system
- Power supply: 12 VDC @ 500 mA
- Connectors: SO-239 on all ports
- Mounting: Outdoors, with weather-resistant box
- Dimensions: 230 mm (w) x 160 mm (h) x 60 mm (d)
- Weight: 1.2 kg approx.
