ICOM IC-7700 HF/50MHz Transceiver

ICOM IC-7700

ICOM IC-7700 top-of-the-line HF transceiver for operators with a common vision of design and value

The essential elements for top-of-the-line HF transceiver performance begin with an exceptionally linear, low distortion design. Starting with electronic component selection, Icom integrates state-of-the-art analog performance with the latest digital technology to achieve superior receiver performance.
As a result, the IC-7700 achieves: more than 110dB dynamic range; more than 40dBm IP3; more than 110dBm IP2 in the HF bands.
Those who choose the IC-7700 will know they have the best receiver performance available. The IC-7700 will change forever what you expect as the normal sound of the HF bands.

Features

• 110dB Dynamic Range and 40dBm IP3
• Better than 110dBm 2nd order intercept point (IP2)
• Double conversion superheterodyne system
• High specification inband IMD
• Band pass filter
• DIGI-SEL (Digital pre-selector)
• Four Pre-amplifiers
• 1st mixer
• Three Hi-Spec 1st IF filters (Roofing Filter)
• 2nd-stage image rejection mixer
• 50MHz band preamplifier and mixer
• Two 32-bit floating point units
• Two AGC Loops
• High stability OCXO unit
• 7-inch wide color TFT LCD
• Two USB ports on the front panel
• RTTY /PSK31 operation without PC connection
• Four antenna connectors
• Real time spectrum scope
• Digital twin PBT
• Digital IF filter
• Manual notch filter and auto notch filter
• Variable noise blanker
• Noise reduction
• Digital voice recorder
• RX audio HPF/LPF setting
• S/P DIF interface
• SSB data mode
• Firmware upgrade for maintaining the best performance
• 200W output power at full duty cycle, full power operation
• Microphone equalizer and adjustable transmit bandwidth
• High speed automatic antenna tuner covering HF to 50MHz band
• Memory keyer
• Set mode function for flexible and speedy setting
• Memory pad stores up to 10 (or 5) operating frequencies
• Quick split function enables split operation with a single action
• SSB/CW synchronous tuning
• Single knob control from squelch volume to RF gain
• UTC/Local Clock and timer function
• 1Hz pitch tuning and 1Hz indication
• 101 memory channels with 10-character comment
• Built-in voice synthesizer announces operating frequency, mode and receiving signal strength
• Programmed scan, memory scan, select memory scan, VSC scan
• Auto tuning step function
• Band edge beep
• Main dial tension control and dial lock
• CI-V interface capability and RS-232C connector for PC connection
• BNC type Transverter connector
• Triple band stacking register
• FFT scope wave averaging function
• Screen saver function
