AOR AR-DV1 SDR Digital Voice Receiver 100 kHz - 1300 MHz

AOR AR-DV1

AOR is pleased to present you with the AR-DV1, the FIRST software defined digital voice receiver to receive and decode virtually ALL popular digital modes such as MOTOTRBO, DMR, dPMR, APCO P25, NXDN, Icom D-Star, Digital CR, Yaesu, Kenwood ®, and Alinco EJ-47U as well as conventional analog signals including AM, wide and narrow FM, upper and lower sideband and CW.

Giving monitoring operators the ability to receive a wide variety of digital and analog frequencies, the AR-DV1 can be used by military, federal, state and local law enforcement agencies, emergency managers, diplomatic services, news-gathering operations, and home monitoring enthusiasts in areas where government, law enforcement, amateur radio operators and public safety agencies use different digital formats.

The AR-DV1 can be operated independently or computer controlled (programmer friendly command list supplied) for easier programming and monitoring.

Features

• Wide frequency coverage: 100 kHz to 1.3 GHz (Cellular blocked for the US consumer version)
• Micro-USB computer interface
• Direct conversion (100 kHz ~ 18 MHz)
• PC controllable with Hyperterminal software by using our COMMAND LIST
• Multi-mode unit capable of receiving AM (Synchronous), USB, LSB, CW, NFM, P25 (APCO25), NXDN, D-STAR, ALINCO EJ-47U, YAESU, DIGITAL CR, dPMR, DMR, MOTOTRBO, KENWOOD ®
• Built-in SD/SDHC card reader for audio recording
• Easy firmware updates through SDHC
• Selectable IF filter bandwidths
• CTCSS and DCS selectable squelch functions
• Built-in voice-inversion descrambling (Not available for the US consumer version)
• AGC
• Auto-notch filter, noise reduction (NR)
• 3 VFO’s, 2,000 alphanumeric memories (50 channels x 40 banks)
