VB-66DX HY-GAIN Directive Antenna 6 elements for the 6 meter band
VB-66DX HY-GAIN Directive Antenna 6 elements for the 6 meter band (50 Mhz) with a gain of 10.3 db. The VB-66DX antenna from HY-GAIN is a directive antenna designed specifically for the 6 meter band ( 50MHz). It is a 6-element high gain antenna, meani
Make the first review405,35€ VAT included 335,00€ excl. VAT
Description HYGAIN VB66DX
VB-66DX
HY-GAIN VB-66DX Directive Antenna 6 elements for the 6 meter band (50 Mhz) with a gain of 10.3 db, The HY-GAIN VB-66DX antenna is a directive antenna designed specifically for the 6 meter band ( 50MHz). It is a 6 element high gain antenna, which means it consists of 6 radiating elements that are used to direct and focus the signal in a specific direction. The VB-66DX antenna has a gain of 10.3 dB, indicating that it is capable of increasing the power of the transmitted signal compared to a standard omnidirectional antenna. This allows better reception and transmission of signals in the 6-meter band, resulting in greater range and performance in communications.
- 1 VB-66DX Antenna
Characteristics
- Frequency 50-54 Mhz
- band 6 meters
- Yagi 6 elements
- Power 1000 watts AM
- Boom Diameter 50.8 mm
- Boom length 7.46mm
- Gain 12.5dbi
- F/B gain 25dB
- wave 1/2
- Impedance 50 ohms
- Minimum and maximum clamp 32/64 mm
- Elements length 2.97 meters
- Diameter elements 11.1 mm
- Weight 7.7kg
