Reference CG3000 EAN 8032182430483

CG3000 ACOPLADOR AUTOMATICO PARA EXTERIOR ANTENAS HF 1.8- 30 Mhz.

CG 3000 AUTOMATIC COUPLER FOR OUTDOOR HF 1.8- 30 Mhz ANTENNAS

CG3000 AUTOMATIC COUPLER FOR OUTDOORS HF 1.8- 30 Mhz ANTENNAS. The CG-3000 tuner is powered by DC 12V. Frequencies 1.8 - 30 Mhz Input impendence: 50 ohms Input power: 10 - 200W PEP SWR: <2: 1 Power supply voltage: 12V +/- 10% Current consumption:

Make the first review

NOTIFY

not available

Description CG3000

PRODUCT DESCRIPTION

! COUPLER FOR EXTERIOR!

CG3000
FOR EXTERNAL AUTOMATIC ANTENNA COUPLER HF 1.8-30 Mhz.
(50 MHz not guaranteed)
It has a 200-channel memory stores the minimum value of ROE for previous links.
Link, in less than 2 seconds in the first adaptation.
The CG-3000 tuner works with DC 12V.
Frequency 1.8 - 30 Mhz
Input impendence: 50 ohms
Input power: 10 - 200W PEP
SWR: <2:1
Power supply voltage: 12V / - 10%
Current consumption: <0.8A
Auto tuning time: Approx. 2 seconds

Memory channels: 200
Weight: 1.8 KG
Size: 310mm X 240mm X 72mm (L - W - H)

CG3000

FEATURES

CG3000
FOR EXTERNAL AUTOMATIC ANTENNA COUPLER HF 1.8-30 Mhz.
The CG-3000 tuner works with DC 12V.
Frequency 1.8 - 30 Mhz
Input impendence: 50 ohms
Input power: 10 - 200W PEP
SWR: <2:1
Power supply voltage: 12V / - 10%
Current consumption: <0.8A
Auto tuning time: Approx. 2 seconds

Memory channels: 200
Weight: 1.8 KG
Size: 310mm X 240mm X 72mm (L - W - H)
