AT500 PALSTAR HF antenna coupler coverage 1.8-54 MHZ / 160 at 6 meters
AT500 PALSTAR HF antenna coupler coverage 1.8-54 MHZ / 160 to 6 meters maximum power 600 W PEP SSB 500 W CW. The Palstar quality and features that Radiographers around the world have come to expect are now available in a compact, low-power tuner at a
Make the first review859,00€ VAT included 709,92€ excl. VAT
Description PALSTAR AT500
PALSTAR-AT-500
AT500 PALSTAR HF antenna coupler coverage 1.8-54 MHZ / 160 to 6 meters Maximum power 600W PEP SSB 500W CW. The quality and features of Palstar that Radiofactors around the world expect now are available in a compact, low-power tuner at an affordable price, the AT-500 600-watt antenna tuner.
Outputs for balanced and unbalanced lines
Impedance adjustment range: from 20 to 1500 Ohms
Easy and fast tuning
6 positions switch for multiple antennas
Active cross needle measurer
Manual in English see << here >>
- 1 Palstar AT-500
features
- Frequencies 1.8 to 54 MHz
- Antenna swith 2 antennas, bypass
- Power measurement range: 0-300W or 0-1000W
- Impedance of 20 to 1500 ohms
- Maximum output power 600 SSB / 500 CW
- Measurer
- balun 4: 1
- Connectors 4 x PL female
- Measures 327 x 263 x 140 mm
- Weight 3.6 kg.
