AA-1500 ZOOM RIGEXPERT Antenna analyzer from 100 Khz to 1,500 Mhz.

RIGEXPERT AA-1500

RIGEXPERT AA-1500-ZOMM Antenna analyzer from 0.1 to 1,500 Mhz. Frequency input: 1 kHz resolution. Measurement for 25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm systems. Display modes: SWR, return loss, R, X, Z, L, C, Magnitude and Phase Angle in one frequency, SWR graph (100 points). SWR chart on fixed HAM bands by IARU regions (100 points), cable tools (speed factor and cable length meter, branch tuner, cable loss chart, cable impedance chart), TDR
Optional open short load calibration in SWR, R, X or Smith/Polar graph modes.
RF output:
– Connector type: N
– Output signal shape: square, from 0.1 to 200 MHz. For higher frequencies, harmonics of the main signal are used.
– Output power: -10 dBm (at 50 ohm load)
Feeding:
– Three Ni-MH batteries 1.2 V, 1800?3000 mAh, type AA
– Max. 3 hours of continuous measurement, max. 2 days in standby mode when using fully charged batteries
: When the analyzer is connected to a PC or to a DC adapter with a USB socket, it draws power from these sources RIGEXPERT AA-1500 Antenna Analyzer 0.1 to 1500 Mhz. Frequency input: 1 kHz resolution

Interface:
– 320×240 color TFT screen –
6×3 keys waterproof keyboard
– Multilingual menus and help screens (English – Spanish – Japanese)
– USB connection to a personal computer
– Bluetooth v. 4.2 (Single Mode, Class B)
Connector: N female. USB connector for PC connection. Multilanguage menus.

Features

• Frequency range: 0.1 to 1500Mhz
• ROE margin: 1 to 100 numerical mode and 1 to 10 graphic mode
• Connector: N female
• Frequency input: 1 kHz resolution.
• Operating temperature: 0ºC to 40ºC
• Color TFT display: 3.2 x 2.4 cm
• 6 x 3 cm spill-proof keyboard
• Measurement for 25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm systems
• USB connector for PC connection
• Memory function for graphics storage
• Fault detection in coaxial cable
• Multilanguage menus
• Software download - see here -
• Power supply: 3 AA 1.5V batteries or 3 AA Ni-Mhde 1.2V batteries
• Measurements: 23 x 10 x 5.5 cm
• Weight: 650g approx
