Reference B550P | ZETAGI

ZETAGI B550P MOBILE TRANSISTORS POWER AMPLIFIER

discontinued

Description ZETAGI B550P

ZETAGI B550P

ZETAGI B550P MOBILE TRANSISTORS POWER AMPLIFIER

Receiver preamplifier, gain 25 db. 6 levels adjustable output power. Protected against polarity inversion.

Features

Receiver preamplifier, gain 25 db
6 levels adjustable output power
Protected against polarity inversion
Frequency: 20 - 30 MHz
Power Supply: 11 - 14 Vdc
Power Supply: 15 - 35 A
Input Power: 1 - 10 W AM
Input Power: 1 - 20 W SSB
Max. Output Power: 300 W AM
Max. Output Power: 600 W SSB
Dimensions (LxWxH): 260 x 160 x 70 mm
Weight: 2.6 kg
