Electrical Data |
- | Type: 1.4-ground plane |
- | Frequency range: 26.5 to 28.5 MHz |
- | Impedance: 50 |
- | Radiation (H-plane): 360 ° omnidirectional |
- | Polarization: vertical |
- | Gain: 0 dBd, 2.15 dBi |
- | Bandwidth @ SW 2000 kHz (180 channels) |
| |
- | Max. Power: 1000 Watts (CW) continuous 3000 Watts (CW) short time |
- | Feed system / position: Gamma match / base |
- | Connector: UHF-female |
| |
Mechanical data |
- | Materials: aluminum, steel, nylon |
- | Wind load / resistance: 242 N at 150 Km / h / 130 km / h |
- | Wind surface: 0.21 m² |
- | Height (approx.): 3640 mm |
- | Weight (approx.): 3900 gr |
- | Mast mounting: 35-42 mm |
