| %u3000Model |
%u3000TAK-300TJX |
| %u3000Image Pick-up Device |
%u30001/3" SHARP COLOR CCD |
| %u3000Horizontal Resolution |
%u3000420 TV Lines |
| %u3000Number of Pixels |
%u3000NTSC:510(H)×492(V); PAL:500(H)×582(V) |
| %u3000Scanning System |
%u3000NTSC:525 Lines,60 Field/sec,
%u3000PAL:625 Lines 50 Field/sec |
| %u3000Sync System |
%u3000Internal Synchronization |
| %u3000Gamma Characterlstic |
%u30000.45 |
| %u3000S/N Ratio |
%u3000%u226548dB(AGC Off) |
| %u3000Electronic Shutter Time |
%u3000On: NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
%u3000Off: NTSC 1/60 Sec, PAL 1/50 Sec |
| %u3000Usable Illumination |
%u30001 Lux(F:2.0) |
| %u3000Lens |
%u3000Board Lens 3.6mm/F2.0(optional)%u3000 |
| %u3000Video Output |
%u30001.0Vp-p 75 ohm |
| %u3000Gain Control(AGC) |
%u3000Auto |
| %u3000Cable |
%u3000BNC JACK |
| %u3000Operation Temperature |
%u3000-10%u2103%uFF5E 50%u2103 RH95% Max |
| %u3000Storage Temperature |
%u3000-20%u2103%uFF5E 60%u2103 RH95% Max |
| %u3000Power Supply |
%u3000DC12V±10% 400mA |
| %u3000Dimension |
%u300080(D) x 70(H)mm |
| %u3000Weight |
%u3000250g |
