Detector metal Localizer

MANUAL

Congratulations  to buy its detector of welcome Garrett metals and to the world of  the search and the exploration!

You have acquired a high tech metal detector and exclusively conceived and developed high performance for which they wish to begin in this exciting world with a detector of high performance.

This technology has impelled to us to integrate a microprocessor to analyze to lar discrimination signals. A screen simplified with the adjustments that  will allow him to adapt better to the land than is going to prospeccionar and the capacity to emit different tones from audio for different types from metal will allow him to distinguish better and more quicklythe targets.

Our plates of the great sensitivity, assure a good penetration in the ground.

You Will appreciate the robustness and quality of manufacture of ours, we have made a particular emphasis in reinforcingthe most sensible points. The materials used for their construction are of Maxima quality and guarantee to their detector onelong life.

Assembly and fits of the detector:

Introduce the rubber washers in the inferior part of theplastic tube and fix the plate to the bar with the screw trying that is assembled well.



Insert the tubes fixing them with clips to form of V, enrosque the cable in the tube, insert the connector of the plate in the connection of the box of control and fíjela



Compartment of the batteries:

Verify that the batteries of the detector  (4 1.5 xs v) are in their compartment sliding the cover  of the box of control towards ahead.

The apoyabrazos are fixed with a screw that can be relaxedwith a screwdriver and allows to vary the position of the apoyabrazos backwards and forwards. Push the apoyabrazos until the position in which one is more comfortable and it returns to tighten the screw.

The use of earpieces is very advisable since the energy consumption is reduced and in addition it is possible to be appreciated with greater clearness small sounds of warning of targets that can not be heard by the loudspeaker. The connection is you locate underneath the box of control and when connecting itself it automatically lets emit signals of audio by the loudspeaker.

Controls and operation:

Once it has mounted the detector it sitúese in a free zone of metal and possible interferences and ignites the equipment pressing switch POWER.

Controls

POWER Enciende and extinguishes the equipment

SENSIVITY  Ajusta sensitivity(power)

MODE Selector of way search.

Description of the screen:

In the superior part we observed a row of 5 rectangular segments of black color that correspond to metal groups classified based on their ferrosidad and conductivity (most ferrous to the left) and  conductivos (for example the silver) towards theright. Upon each segment the name in English of the possible metal is written that corresponds to him.

When one takes place a finding appears another right segment upon

segment to which it corresponds (By ej. If one ignites underneath iron it means

that it has detected an iron object.

When we pressed MODE we changed the type of discriminationand different segments will be extinguished or ignited. If the segment is dull, when a finding takes place that corresponds to this segment, the equipment will not emit any signal of audio, to this end discrimination is called to him and it is used to eliminate signals nonwished.

All metal (All metal) the detector will indicate all the metals that locates.

JEWERELY (Way jewels) will extinguish to the segment corresponding to the iron detecting all metals except this one.

COINS (currencies) will extinguish the segment corresponding to the iron and to the aluminum washers of the softdrink cans

The depth indicator COIN DEPH of will give a approximate idea (in inches) of a that depth is the target.
