MVX-120 Universal Motor MVISION parabolic max. 120

MVISION MVX120 64477
Discontinued product.
  • MVX120
  • Motor MVISION MVX-120 for satellite dishes up to 120 cm and a rotation angle of 150 º. Recognizes...

    More info


  • Not Available

We're working in our new page, i'ts possible that you discover some mistakes.

In that case, you can notify us

clicking HERE..

Equivalent Products

MVX-120 Universal Motor MVISION parabolic max. 120

Motor MVISION MVX-120 for satellite dishes up to 120 cm and a rotation angle of 150 º. Recognizes the DiSEqC 1.2 and USALS (goto x function). Manufactured in metal.


MVISION MVX120



FEATURES

Maximum size of antenna: 120 cm
Speed: 1.9 / sec (13v), 2.5 / sec (18v)
Azimuth Angle: 75 degrees east - 75 degrees west (160 degrees max.) Adjustable
Elevation angle: 25 º to 75 º
Storable Positions: 100
2-button hand (east / west)
Two-color LED indicator
Sensor for high resolution positioning
Weight: 3.5 kg
Dimensions: 335 x 175 x 115 mm3
