ATS505 SANGEAN Escaner receiving of radium FM/ STEREO/ MW/ LW/ SW FUND

 61040
Discontinued product.
  • ATS505
  • ATS505 SANGEAN Escaner receiving of radium FM/ STEREO/ MW/ LW/ SW FUNDA + AURICULARES

    More info


We're working in our new page, i'ts possible that you discover some mistakes.

In that case, you can notify us

clicking HERE..



ref: ATS505 ATS 505 SANGEAN Escaner receiving of radium FM/ STEREO/ MW/ LW/ SW FUNDA + AURICULARES

MAIN CARACTERISTICAS

 - Sintonia continuous from 150khz to 30 Mhz.
 - Wave Cuts (Manner AM and SSB) with coverage continuous from 1711 to 29999 KHz.
 - Wave Lets Go OL, Wave Is OM and Frequency Modulation FM stereo
 - Five manners of syntony different, AutoStore, etc
 - Receiver of double conversion of frequency connection stops aerial outer
 - 45 memories/ Jump of frequency of 1 KHz control of tonality
 - Clock double time with two temporizadores
 - Includes headsets estereo and cover
 - Food 4 batteries AA






Dress front Scanner ATS505



Sights lateral Scanner ATS505





Dress posterior Escaner ATS505



Sight front with cover of the escaner ATS505




 - Requirements electrical: 6V
 - Batteries: 4 x size lEC LR6 (AA) (UM 3 )

Characteristic of the circuit

 - Semiconductors: 1 LSI 7 IC, 35 transistors, 7 FET, 33 diodes, 3 LED

System of aerials

 - Internal of ferrite for AM/ LW
 - Telescopic for SW
 - Telescopic for FM

 - Power of exit: 300 mW 10% T.H.D.

Plugs

 - Stops the headsets: 3,5 mm in diameter stereophonic
 - Takes of CC: Of 6 volts with the negative in the sideburn central
 - Accessories included: Bag of transport and headsets estereo

 - Sizes: 214 (A) x 128 (a) x 38.50 (p)

 - Weight: 840 g without batteries.
