EL0151E Proteje mains and antenna - 5 TAKINGS CURRENT, 1 ANTENNA

The 0151 and Proteje mains and antenna Includes: 1.8 antenna cable m.s. It assures one complete protection against surges and tips of tension produced by electrical storms, short circuits, static electricity, etc. It avoids interferences and the e more Reference EL0151E EAN 8413173240227

available
20,73 incl. VAT
17,13€ w/o VAT
Delivery price from 30,25€
We're working in our new page, i'ts possible that you discover some mistakes. In that case, you can notify us clicking HERE.

DESCRIPTION OF THE PRODUCT

ref: EL0151E

The 0151 and Proteje mains and antenna

It assures one complete protection against surges and tips of tension produced by electrical storms, short circuits, static electricity, etc.

It avoids interferences and the effects of the electrical noise (responsible for errors and loss of data, disconnections nonwished of line, interruptions of signal, etc.

Protection of the apparatuses connected to the installation of the antenna and the telephone line.

It has a safety to children (stoppers)

Takings of input/output of antenna signal

5 standard Tomas

It has an indicator that it indicates that the circuits of protection estan verified and ready to work.


EL0151E


CHARACTERISTICS

Nominal current: 10 A
Nominal tension: 250 V - 50 Hertz
Maximum power: 2300 W to 230 V
Voltage maximo: 775 V
Maxima energy: (H-N, H-G, N-G) 714 Joules
Maxima current:
       - Type bases: 6500 A
       - complete Type: 19500 A
Voltage: "tip" 6 kV
Response time: < 1 ns
Filter against noises in line and transientes:
       - Rank of frequency: 150 Khz - 100 Mhz
       - Absorption: up to 40 dB
