KENWOOD TS-990S HF / 50 MHz transceiver

KENWOOD TS-990S HF / 50 MHz transceiver

TS990S

Referencia: TS990S

stock

7.550,40 incl. VAT

6.240,00€ w/o VAT

BUY NOW

Keyboard Front Panel Yes
Headphone Connector with Dual Output RX Yes, primary and secondary RX Audio can be heard mixed or separately for the right / left channel

Key Lock Yes

Puerto LAN Yes Speaker Socket Two external speakers can be connected via 3.5mm connectors. Impedance 4 8 ohms Channel memory with alphanumeric label 120 memory channels

Zócalo microphone 8 pins type "Chrome"
Function Mute Yes
PC Program Radio Control (Optional) Yes
Pre Amplifier Yes, configurable band
Pre selector Yes, Configurable
Programmable Function keys Yes, 9 keys PF
Compatible PSK31 Yes
remote Operation via Internet Software allows remote management ARHP 990
Roofing Filter Equipped with 270Hz, 500Hz, 2.7kHz, 6kHz and 15kHz as standard
Sky Command 2 Yes

Voice Processor Yes

secondary receiver Yes, equivalent to primary receiver TS 590S TFT Color Display Yes, 2 TFT screens. Main screen 7 "bandscope function, Waterfall tuning and touch screen more secondary display 3.5" display audio, tuning meter PSK, etc. Selectable color background. 4 types of presentation of the secondary meter S. Display includes XY (FSK) function and vector function (PSK) USB Port Yes, 3 USB ports. 2 x USB flash A / keyboard memories. 1 x USB B for connecting PC Specifications HF Amateur Output Power HF 200 W SSB / FM / CW / FSK, 50 W AM

RF output power 50 MHz 200 W SSB / FM / CW / FSK, 50 W AM

supply voltage AC 220 240 V (50/60 Hz) antenna Impedance 50 Ohms Yes antenna coupler (160 Bands 6 m) 16.7 Ohm 150 Ohm Yes Audio Output Impedance 8 Ohm Yes Audio power Output Superior 1.5 W (8 Ohm, 10% distortion) continuous reception:

(approx.) 30 kHz 60 MHz Yes, specification 0.13 30 & 50 MHz 54 MHz consumption Power consumption 840 VA TX / RX power consumption 200 VA

Frequency Stability ± 0.1 ppm 0 ° C to 50 ° C

impedance microphone 600 Ohm Yes

A1A (CW), A3E (AM), J3E (SSB), F3E (FM), F1B (FSK) & Mode G1B (PSK)

Notch Filter Attenuation Superior Auto Mode Manual Mode 60 dB to 70 dB Superior

operating temperature 0 ° C to 50 ° C Kenwood TS 990 SElimination Batido Greater than 40 dB Reception

Circuitry Double superheterodyne receiver main receiver RX1 Sub Conver lower sion Double superheterodyne Sub RX2 upconversion Triple superheterodyne

Frequency Range Front Coverage VFO = 30kHz 60MHz Specification main band guaranteed = 0.13 30MHz / 50 54MHz

Rejection FI Reception Less than 70dB

Image Rejection Front HF Less than 70dB 50MHz Less than 60dB Receiver Intermediate frequency main receiver 1st IF 8.248 MHz / 2nd IF 24 kHz (FM 455 kHz) Sub RX1 lower conversion 1st IF 11.374 MHz / 2nd IF 24kHz Sub RX2 higher conversion 1st IF 73095 MHz / 2nd IF 10.695 MHz / ª FI 24kHz (FM 455 kHz) Selectivity Reception SSB (LOW: 200 / HIGH: 2800 Hz) More than 2.4 kHz @ 6 dB / Less than 4.4 kHz @ 60dB CW / FSK / PSK (Width: 500 Hz): More than 500 Hz @ 6 dB / Less than 1.2 kHz @ 60 dB AM (LOW: 100 / HIGH: 3000 Hz) More than 6 kHz @ 6 dB / Less than 12 kHz @ 60dB FM More than 12 kHz @ 6 dB / Less than 25 kHz @ 50dB receiving Sensitivity 0.13 0.522 MHz SSB / CW / FSK / PSK = less than 0.5µV AM = less than 6.3µV
receiving Sensitivity 0.522 1 .705 MHz SSB / CW / FSK / PSK = less than 4µV AM = less than 32µV
Receiving Sensitivity 1,705 24.5 MHz SSB / CW / FSK / PSK = less than 0.2µV AM = less than 2µV Receiving Sensitivity 24.5 30 MHz SSB / CW / FSK / PSK = less than 0.13µV AM = less than 1.3µV
receiving Sensitivity 28 30 MHz (FM) less than 0.22µV
receiving Sensitivity 50 54 MHz SSB / CW / FSK / PSK = less than 0.13 microvolts AM = less than 1.3µV 0.22µV FM = less than
frequency Range ± 9.999 kHz RIT
carrier suppression less than 60 dB

response transmission frequency (SSB) 300 Hz 2700 Hz (within 6 dB)

Modulation transmit SSB / FM / AM = Balaceada / reactance / Low Power Kenwood TS 990 SRadiation Spurious Less than 60dB

Radiation Spurious transmission 50 MHz Less than 66 dB

Deleting unwanted sideband Less than 60dB

frequency Range XIT ± 9.999 kHz

Dimensions W x H x D = 460 x 165 x 400 mm without projections Kenwood TS 990 SWeight 24.5 kg



Kenwood TS 990 S



Kenwood TS 990 S



Kenwood TS 990 S



Kenwood TS 990 S



Kenwood TS 990 S



Kenwood TS 990 S







Kenwood TS 990 S



Kenwood TS 990S video presentation.





Kenwood TS 990S Video presentation





Ham Radio Station "IV3YER"







Ham Radio Station "IV3YER"









Features


Range
frequency
(Transmitter)
band 160m 1.81 ~ 2.0 MHz
band 80m 3.5 ~ 3.8 MHz
band * 1
60m 5.25 ~ 5.45 MHz
band 40m 7.0 ~ 7.2 MHz
band 30m 10.1 ~ 10.15 MHz
band 20m 14.0 ~ 14.35 MHz
band 17m 18,068 ~ 18,168 MHz
band 15m 21.0 ~ 21.45 MHz
band 12m 24.89 ~ 24.99 MHz
band 10m 28.0 ~ 29.7 MHz
band 6m 50.0 ~ 52.0 MHz
frequency range
(Receiver) *
2
0.13 ~ 30 MHz, 50 ~ 54 MHz
VFO: Continuous 30 kHz ~ 60 MHz
Mode
A1A (CW), A3E (AM), J3E (SSB), F3E (FM)
F1B (FSK), G1B ( PSK)
frequency Stability ± 0.1 ppm (0 ° C ~ 50 ° C)
antenna Impedance 50 O
range antenna coupler 150 7.16 O ~ O
voltage AC 220 ~ 240 V (50/60 Hz)
margin feed ± 10% (AC 198 V ~ 264 V)
consumption
current
in transmission
(max)
= 840 VA
in reception
(no signal)
= 200 VA
Temperature range 0 ° C ~ 50 ° C
Dimensions
No projections 460 W x 165 x 400 mm P
With An projections 460 x 182 x 449 mm P
foot. pos. extended to 201 mm (front panel), Al 173 mm (rear panel)
Weight Approx. 24.5 kg
Transmitter
Power
Output
CW / SSB / FSK /
PSK / FM (AM)
200 W (50 W)
Modulation SSB: Balanced, AM: Low power FM reactance
Maximum frequency deviation ( FM) width = ± 5 kHz, narrow: = ± 2.5 kHz
spurious Emission
HF (Harmonics): = 60 dB
HF (other): = 50 dB
50 MHz: = 66 dB
carrier Suppression = 60 dB
Deletion unwanted sideband = 60 dB
frequency response transmission within the margin 6 dB (300 ~ 2700 Hz)
impedance microphone 600 O
Variable band XIT ± 9.999 kHzCaracterísticas General Amateur Radio
Port E / S Reference 10 MHz Yes
"Elimination Filter Band" Yes
Display bands scope If
Manipulator CW including memory Messaging Yes
power supply included PSU type Switched
Unity voice Guide and Record included If
Clock Yes
Puerto COM D sub 9-pin Yes
Connectivity: 10MHz reference Oscillator (BNC) Input keyboard external port ATU COM port (9-pin female) Manipulator P addle (6.3mm jack) 2 USB A, 1 B USB Audio / Data "ACC 2" connector "Remote" Jack 3.5 mm gauge "DRV" low level LF drive Optical input / SPDIF two external speaker connectors (jacks 3.5mm) connector I Dual DVI video port LAN port link
Connector for External ATU If
Connector for remote linear amplifier If
optical digital port Yes, I / O
Tecla 4 levels of illumination If display lighting and LEDs.
Shortcut buttons Banda Yes, 10 buttons 1.8 Amateur bands 50 MHz plus 2 buttons for general coverage. Up to 5 bands memory button
Direct Input frequency Yes
output terminal low excitation "DVR" Yes, Jack RCA 1 mW output covers bands 1.8 to 50 MHz more 135.80 137.70 kHz band LF
Reception dual Yes
DSP devices DSP 3 devices Analog devices Inc SHARC 32 bit for FI main, secondary and function FI bandscope
Functions Equalizer DSP RX 3 user settings
Actualización de firmware via puerto USB Sí
Teclado en panel Frontal Sí
Conector auricular con salida doble RX Sí, Audio principal y secundario de RX puede ser escuchado mezclado o separadamente por el canal derecho/izquierdo
Bloqueo teclas Sí
Puerto LAN Sí
Zócalo altavoz Dos altavoces externos pueden ser conectados vía los conectores 3.5mm. Impedancia 4 8 ohms
Canales memoria con etiqueta alfanumérica 120 Canales de memoria
Zócalo micrófono 8 pins tipo "Chrome"
Función Mute Sí
Programa PC Radio Control (Opcional) Sí
Pre amplificador Sí, Configurable por banda
Pre selector Sí, Configurable
Función Teclas Programables Sí, 9 teclas PF
Compatible PSK31 Sí
Operación Remota vía Internet Software ARHP 990 permite gestión remota
Filtro Roofing Equipado con 270Hz, 500Hz, 2.7kHz, 6kHz y 15kHz como estándar
Sky Command 2 Sí
Procesador de Voz Sí
Receptor secundario Sí, Equivalente al receptor principal TS 590S
Display TFT Color Sí, 2 pantallas TFT. Pantalla principal de 7" con función Bandscope, Cascada y pantalla táctil de sintonización más pantalla secundaria de 3,5" con visualización de audio, medidor de sintonía PSK, etc. Color de fondo seleccionable. 4 tipos de presentación del medidor S. Display secundario incluye la función X Y (FSK) y la función vectorial (PSK)
Puerto USB Sí, 3 puertos USB. 2 x USB A para memorias flash / teclado. 1 x USB B para conexión PC
Especificaciones HF Amateur
Potencia de salida HF 200 W SSB/FM/CW/FSK, 50 W AM
Potencia de salida RF 50 MHz 200 W SSB/FM/CW/FSK, 50 W AM
Tensión de alimentación A.C. 220 240 V (50/60 Hz)
Impedancia de antena 50 Ohm Sí
Acoplador de antena (160 6 m Bandas) 16.7 Ohm a 150 Ohm Sí
Impedancia de Salida de Audio 8 Ohm Sí
Potencia Salida Audio Superior a 1,5 W (8 Ohm, 10% distorsion)
Recepción continua: 30 kHz 60 MHz Sí, En especificación 0.13 30 MHz & 50 54 MHz
Consumo (aprox.) Potencia de consumo TX 840 VA / Potencia de consumo RX 200 VA
Estabilidad de Frecuencia ± 0.1 ppm 0 °C a 50 °C
Impedancia de micrófono 600 Ohm Sí
Modo A1A (CW), A3E (AM), J3E (SSB), F3E (FM), F1B (FSK) & G1B (PSK)
Filtro de Atenuación Notch Modo Auto Superior a 60 dB Modo Manual Superior a 70 dB
Temperatura de funcionamiento  0 °C to 50 °C
Eliminación Batido Recepción Mayor que 40 dB
Circuiteria Receptor Receptor principal Doble superheterodina Sub RX1 Conversión inferior Doble superheterodina Sub RX2 Conversión superior Triple superheterodina
Rango Frecuencia Recepción Cobertura VFO = 30kHz 60MHz Especificación banda principal garantizada = 0.13 30MHz/50 54MHz
Rechazo FI Recepción Menor que 70dB
Rechazo de Imagen Recepción HF Menor que 70dB 50MHz Menor que 60dB
Frecuencia Intermedia Recepción Receptor principal 1ª FI 8.248 MHz/2ª FI 24 kHz (FM 455 kHz) Sub RX1 Conversión inferior 1ª FI 11.374 MHz/2ª FI 24 kHz Sub RX2 Conversión superior 1ª FI 73.095 MHz/2ª FI 10.695 MHz/ª FI 24 kHz (FM 455 kHz)
Selectividad Recepción SSB (BAJA:200/ALTA:2800 Hz) Más de 2.4 kHz @ 6 dB/Menor que 4.4 kHz @ 60dB CW/FSK/PSK (Ancho: 500 Hz): Más de 500 Hz @ 6 dB/Menor que 1.2 kHz @ 60 dB AM (BAJA:100/ALTA:3000 Hz) Más de 6 kHz @ 6 dB/Menor que 12 kHz @ 60dB FM Más de 12 kHz @ 6 dB/Menor que 25 kHz @ 50dB
Sensibilidad de recepción 0.13 0.522 MHz SSB/CW/FSK/PSK = menor que 0.5µV AM = menor que 6.3µV
Sensibilidad de recepción 0.522 1.705 MHz SSB/CW/FSK/PSK = menor que 4µV AM = menor que 32µV
Sensibilidad de recepción 1.705 24.5 MHz SSB/CW/FSK/PSK = menor que 0.2µV AM = menor que 2µV
Sensibilidad de recepción 24.5 30 MHz SSB/CW/FSK/PSK = menor que 0.13µV AM = menor que 1.3µV
Sensibilidad de recepción 28 30 MHz (FM) Menor que 0.22µV
Sensibilidad de recepción 50 54 MHz SSB/CW/FSK/PSK = menor que 0.13µV AM = menor que 1.3µV FM = menor que 0.22µV
Rango de frecuencia RIT ± 9,999 kHz
Supresión de portadora Menor que 60 dB
Respuesta en frecuencia de transmisión (SSB) 300 Hz 2700 Hz (dentro de 6 dB)
Modulación en Transmisión SSB/FM/AM = Balaceada/Reactancia/Baja Potencia
Radiación Espurias Menor que 60dB
Radiación transmisión Espuria 50 MHz Inferior a 66 dB
Supresión de banda lateral no deseada Menor que 60dB
Rango de frecuencia XIT ± 9,999 kHz
Dimensiones An x Al x F = 460 x 165 x 400 mm sin proyecciones
Peso 24,5 kg



Kenwood TS 990 S
