GPS12 SIRIO based CB 27 Mhz Antenna, 1/2 wave. 6 meters length

GPS12 SIRIO Antena base CB 27 Mhz, 1/2 onda. Longitud 6 metros 68467
Not available product.
  • GPS12
  • GPS12 SIRIO based CB 27 Mhz Antenna, 1/2 wave. 6 meters length

    More info

  • 35,00€
  • VAT not included

We're working in our new page, i'ts possible that you discover some mistakes.

In that case, you can notify us

clicking HERE..

SIRIO GPS 27 1/2. 26 CB Antenna 28 Mhz. 1/2 wave.

Ideal for installation in zoteas, roof antenna.
Widely used for lengthening distance contacts (DX).
Frequency 27Mhz, Power 500W, Gain 2.15dBi, Connection type PL

GPS27 CB 1/2 wave antenna base.
Reinforced Aluminum.
IPad polyethylene together.
Transparent Reinforced coil.
50 Ohm impedance.
Frequency 26 28 MHz.
Omnidirectional.
Vertical polarization.
Pot. max. 500 W.
VSWR <1.2: 1.
GPS27 2.15 dBi gain.
GPS27 length 5950 mm.
Pesos 2100

sirio gps 27 1/2. antena cb 26 28 mhz. 1/2 onda.



FEATURES

Electrical Data
Type:

GPS 27 1/2
Frequency range: 26 28 MHz
Impedance: 50O unbalanced
Radiation (H plane): 360 ° omnidirectional
Polarization: Vertical
Gain:

GPS 27 1/2: 2.15 dBi
Bandwidth at VSWR 2: 1: 1400 KHz
VSWR at res. freq .: = 1.2: 1
Max. Power: 500 Watts
Feed system / position: Transformer DC ground / base
Connection: UHF female

Mechanical Data
Materials: Aluminium, Steel, Copper, Nylon
Wind resistance: 130 Km / h
Wind load:

GPS 27 1/2: 156 N at 150 Km / h
Wind surface:

GPS 27 1/2: 0.11 m²
Height (approx.):

GPS 27 1/2: 5950 mm
Weight (approx.): 2100 gr

Mounting mast: Ø 35 42 mm

sirio gps 27 1/2. antena cb 26 28 mhz. 1/2 onda.
