GPE58 SIRIO Antena base CB 27 Mhz, 5/8 onda. Longitud 6 metros

SIRIO GPE 27 5/8. Antena CB 26-28 Mhz. 5/8 onda. 68466
Available product.
  • GPE58
  • SIRIO GPE 27 5/8. Antena CB 26-28 Mhz. 5/8 onda. Antena ideal para instalar en zoteas, tejados, poco...

    More info

  • 39,00€
  • VAT not included

We're working in our new page, i'ts possible that you discover some mistakes.

In that case, you can notify us

clicking HERE..

SIRIO GPE 27 5/8. 26 CB Antenna 28 Mhz. 5/8 wave.

Ideal for installation in zoteas, roofs, inconspicuous antenna.
Widely used for its great performance in town.
Frequency 27Mhz, Power 500W, Gain 3,35dBi, Connection type PL

FEATURES

GPE27 Cb 5/8 wave antenna base.
Reinforced Aluminum.
IPad polyethylene together.
Transparent Reinforced coil.
50 Ohm impedance.
Frequency 26 28 MHz.
Omnidirectional.
Vertical polarization.
Pot. max. 500 W.
VSWR <1.2: 1.
GPE27 3.35 dBi gain.
GPE27 length 5950 mm.
Pesos 2500 Gr
. Long. rad. GPE27 1320 mm.

sirio gpe 27 5/8. antena cb 26 28 mhz. 5/8 onda.



FEATURES

Electrical Data
Type: GPE 27 5/8: 5/8 ground plane
Frequency range: 26 28 MHz
Impedance: 50O unbalanced
Radiation (H plane): 360 ° omnidirectional
Polarization: Vertical
Gain: GPE 27 5/8: 1.2 dBd, 3.35 dBi
Bandwidth at VSWR 2: 1: 1400 KHz
VSWR at res . freq .: = 1.2: 1
Max. Power: 500 Watts
Feed system / position: Transformer DC ground / base
Connection: UHF female

Mechanical Data
Materials: Aluminium, Steel, Copper, Nylon
Wind resistance: 130 Km / h
Wind load: GPE 27 5/8: 188 N at 150 Km / h
Wind surface: GPE 27 5/8: 0.13 m²
Height (approx.): 27 5/8 GPE: 5950 mm
Weight (approx.): 2500 gr
Radial length (approx.): 27 5/8 GPE 1320 mm
Mounting mast: Ø 35 42 mm

sirio gpe 27 5/8. antena cb 26 28 mhz. 5/8 onda.
